Assembly Instruction Sheet #IS-NA1514BN
For Style NA1514BN
STEP 8
- Attach Shades to fixture
A. Place Inner Shade (K) into Outside Shade (L).
B. Pass the Hole on the Outside Shade (L) through Side
Rod. Secure by thread Lock Ball (J) onto Side Rod,
hand tighten until snug.
Your fixture is now assembled and ready to use.
Enjoy!
Figure 9
