5of6
Assembly Instruction Sheet #IS-NA1514BN
For Style NA1514BN
STEP 6
- Attach Ceiling Canopy to Mounting
Screw
A. Place the Ceiling Canopy (F) over the Mounting Screws
(B) and secure with Mounting Balls (E). Hand tighten
until snug.
Mounting
Screw
Mounting
Ball
Ceiling Canopy
Figure 7
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
, .
. .
2014 QuoizelInc.
STEP 7
- Install Bulb
A. This fixture uses standard bulb with a standard screw
base. Maximum 100 watts.
B. Insert bulb and screw properly into place.
Figure 8
Socket
Bulb
July2014
