Quoizel TFAS1507VA Asheville User Manual
Page 2
1
PART NUMBER
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2
"
REPLACEMENT PART DESCRIPTION
REQ.
NO.
2of5
(1)100W Medium
Base Bulb
(Not Supplied)
TFAS1507VA
6”
12”
FINISH: VALIANT BRONZE
GND
2.4mm
13Ga
QUOIZEL
R
5.5" Sq.
1.5”
11.5”
5”
7” Sq.
50.5”
OVERALL HEIGHT INCLUDES
(2) 6” AND 12” RODS
2
3
9012EXVA
9006EXVA
G3574SH
ROD EXT
12"L X 0.5"D
VALIANT BRONZE
ROD EXT
6"L X 0.5"D
VALIANT BRONZE
TIFFANY SHADE 7"SQ
2
2
1
3
2
1
