Assembly Instruction Sheet #IS-CKAD836PN

For Style CKAD836PN

STEP 1

Assemble Ceiling Canopy, Fixture

Chain, Fixture Body together

-

A. Attach one end of Fixture Chains (G) to the Ceiling

Loops on the bottom of Ceiling Canopy (H) with (2)
Quick Links (B), attach the other end of Fixture Chains
(G) to the Loops on the top of Fixture Body (L) with
another (2) Quick Links (B).

Ceiling
Canopy

Fixture Chain

Figure 1

Ceiling Loop

Fixture Body

Loop

STEP 2 - Attach Nipple to Crossbar

A. Thread one Hex Nut (E) onto top end of the Nipple C .
B. Place one Lock Washer D over the top end of the

Nipple C and then thread the Nipple C into the center
hole of the Crossbar A . Hand tighten until snug.

C. Using pliers, thread the Hex Nut

against the

Crossbar A and hand tighten until snug.

( )

( )

( )

( )

( )

(E)

( )

Figure 2

Crossbar

Lock Washer

Hex Nut

Nipple

STEP 3

Attach Inner Crossbar to Outlet Box

-

A. Attach the Crossbar (A) to Outlet Box and secure by

threading Outlet Box Screws (not supplied) into the
Mounting Holes on the Outlet Box. Tighten until snug.

Figure 3

Outlet Box

Outlet Box
Screw (not
Supplied)

Crossbar

Quick Link

Quick Link
