STEP 11 - Attach Crystal Assembly
A. Thread the nipple on the top end of the Crystal
Assembly (P) into the Coupling at the Ring. Hand
tighten until snug.
Assembly Instruction Sheet #IS-UPCC2825IS
For Style UPCC2825IS
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
, .
. .
2012 QuoizelInc. October2012
Crystal
Assembly
Figure 12
STEP 12 - Install Bulb
A. This fixture uses standard bulb with medium screw
base. Maximum 100 watts.
B. Insert bulb and screw snugly into place.
Your fixture is now assembled and ready to use. Enjoy!
Figure 13
Bulb
Socket
Coupling
Ring
