6 front bezel, Front bezel – Compaq EXS Series User Manual
Page 33
4-6
Removal & Replacement Procedures
4.6
Front Bezel
1.
Prepare the computer for disassembly (Section 4.2).
WARNING: Power is continuous to the system board and power supply even when the power
switch is turned off. To prevent damage to the unit, disconnect the power cord from the power
source or the unit before beginning disassembly procedures.
2.
Remove the access panel (Section 4.5).
3.
Press the release tabs
1 on the side of the front bezel.
4.
Rotate the front bezel away from the chassis to remove it from the unit
2.
✎
When replacing the front bezel, ensure that the bottom hinge points are properly
placed in the chassis before rotating the front bezel back into its original position.
