Quoizel CKMS2822TM Marisol User Manual
Page 2
CKMS2822TM
1
PART NUMBER
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2
"
REPLACEMENT PART DESCRIPTION
REQ.
NO.
2of6
FINISH: TECO MARRONE
GND
2.4
mm
13
Ga
QU
I OZ
EL
M2041CHTM
CHAIN TECO MARRONE 4'L 4.5MM
1
2
G3683DI
ETCHED GLASS DIFFUSER 18.25"D
1
3
S1537BE
SHADE BEIGE 19"D X 8"H
1
6” Dia.
1”
30”
19” Dia.
22” Dia.
8”
8”
Overall Height 85”
(Includes 48” Chain and 2 Quick Link)
1
3
2
(4)100W Medium
Base Bulbs
(Not Supplied)
