Quoizel KPR5009BN Kemper User Manual
Page 2
KPR5009BN
2of6
GND
2.4mm
13Ga
QUOIZEL
R
6”
12”
FINISH: BRUSHED NICKEL
1
2
PART NUMBER
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2
"
REPLACEMENT PART DESCRIPTION
REQ.
NO.
3
(9)100W
Medium Base Bulb
(Not Supplied)
NOTE: FOUR LIGHTS SHOWN FOR
ILLUSTRATION PURPOSES ONLY.
6.5” Dia.
1”
63”
OVERALL HEIGHT INCLUDES
(2) 6” AND 12” RODS
(1)50W MR-16
Gu10 Base Bulbs
(Supplied)
6” Dia.
5”
31.5”
34” Dia.
G3644SH
9006EXBN
9012EXBN
GLASS WHITE PAINTED INSIDE 6"D
ROD EXT BRUSHED NICKEL 6"L X 0.5"D
ROD EXT BRUSHED NICKLE 12"L X 0.5"D
9
2
2
1
2
3
