STEP 4:
*
. .
.
.
. ,
.
.
.
Plier is required on this step
Thread one Hex Nut onto top end of the Nipple
Place one Lock Washer over the top end of the
Nipple and then thread the Nipple into the
center lock hole of the Crossbar
Us plier thread the Hex Nut against the
rossbar and hand tighten until snug
Thread another Hex Nut onto the bottom end of
the Nipple
.
a
b
c ing
c
d
Crossbar
Lock Washer
Hex Nut
Hex Nut
Nipple
3 OF 4
Nipple
Lock Washer
Canopy Chain Loop
Ceiling Canopy
Fixture Chain
Canopy Lock Ring
Hex Nut
Fixture Loop
STEP 5 :
a Adjust the Fixture Chain to your desired length by
removing the links if needed
P lease note that depends on chain material
thickness you might be required to use chain
pliers to spread links open
b Pull the supply wir es through the Fixture Chain
alternating links And then pull the wires thr ough
the following components in turn
Canopy Lock Ring Ceiling Canopy Canopy
Chain Loop, Lock Washer and Nipple
c Place Lock Washer over the end of the Nipple and
thread the Canopy Chain Loop onto the end of the
Nipple
d Using plier thread the Hex Nut against the
Canopy Chain Loop and tighten until snug
e Attach one end of the Fixture Chain onto the
Fixture Loop and attach the another end of the
chain onto the Canopy Chain Loop
f Refer to S tep 6 Wire Connections to connect
wires
g Push the Ceiling Canopy upward over the Outlet
Box
h Thread the Canopy Lock Ring onto the Canopy
Chain Loop and tighten until snug to secure the
Ceiling Canopy
.
.
*
,
.
.
.
:
, ,
, .
.
.
. ,
.
.
.
. -
.
.
.
.
.
STEP 6 :
* ( )
.
.
.
( )
. ( )
( ).
.
.
Use Wire Connectors not supplied to connect
the wires
a Connect the House Ground Wire to the Fixtur e
Ground Wire.
b Connect the House White Wire to the Fixture
Supply Wire White or Ribbed Side .
c Connect the House Black or Red Wire to the
Fixture Supply Wire Black or Smooth S ide
d Wrap each connection with approved electrical
tape and carefully stuff all of the connected wires
into the Outlet Box
WHITE WIRE
BLACK OR RED WIRE ( )
FROM HOUSE
GROUND WIRE GROUND WIRE
FROM HOUSE FROM FIXTURE
WHITE OR RIBBED
FROM FIXTURE FROM HOUSE
FROM FIXTURE
BLACK OR SMOOTH
INSTALLATION INSTRUCTIONS STYLE NUMBER IE28 25BN :
