Figure 2: crawl space / attic cut-away – Quoizel GE5009SE Genova User Manual
Page 3
FIGURE 2: CRAWL SPACE / ATTIC CUT-AWAY
CEILING WALL BOARD
JUNCTION BOX
COUPLING
NIPPLE
CEILING CANOPY
CANOPY CHAIN LOOP
FIXTURE CHAIN
HEX NUT with SHAKE PROOF
WASHER
WOOD BRIDGING MEMBER
CEILING JOISTS
3/8-18 NIPPLE (INCLUDED)
HOUSE / FIXTURE
SUPPLY WIRES
COTTER
PIN
(installed above
HEX NUT)
IS-GE5009
Page 3 of 3
12.05
