4-2
Cisco Service Control Engine 1000 2xGBE Quick Start Guide
OL-7822-06
Chapter 4 Connect the Management Interfaces and Perform Initial System Configuration
Perform the Initial System Configuration
The above SCE 1000 port parameters are fixed and are not configurable.
Step 1 Plug the serial cable provided with the SCE 1000 into the CON port on the front panel of the
SCE 1000.
Step 1 Connect the other end of the serial cable (with an attached DB-9 connector) to the VT100 compatible
local (serial) terminal.
Step 2 At the console. press
Step 3 Enter
Step 4 several times until the Cisco logo appears on the local terminal and the setup configuration dialog is
entered.
--- System Configuration Dialog ---
At any point you may enter a question mark ‘?’ followed by ‘Enter’ for help.
Use ctrl-C to abort configuration dialog at any prompt.
Use ctrl-Z to jump to the end of the configuration dialog at any prompt.
Default settings are in square brackets ‘[]’.
Would you like to continue with the System Configuration Dialog? [yes/no]: y
Step 5 Type y and press press Enter.
Enters the system configuration dialog.
Perform the Initial System Configuration
• Initial System Configuration, page 4-2
• Step 1: Configuring Initial Settings, page 4-6
• Step 2: Configuring the Hostname, page 4-7
• Step 3: Setting the Passwords, page 4-7
• Step 4: Configuring Time Settings, page 4-8
• Step 5: Configuring the DNS Settings, page 4-10
• Step 6: Configuring the RDR Formatter Destination, page 4-12
• Step 7: Configuring Access Control Lists (ACLs), page 4-12
• Step 8: Configuring SNMP, page 4-16
• Step 9: Configuring the Topology-Dependent Parameters, page 4-20
• Step 10: Completing and Saving the Configuration, page 4-22
Initial System Configuration
• The Setup Command, page 4-3
• Setup Command Parameters, page 4-4
• Example, page 4-6
