4
1
2
3 4 7 8 6 5
Features and Technical Data
Cooking Zones
1. Hi-light cooking zone Ø 140 mm - 1200 W
2. Double hi-light cooking zone Ø 180/120 mm - 1700/700 W
Touch-Control Description
3. ON/OFF key
4. Front zone (1) keys (increasing and decreasing power)
5. Rear zone (2) keys (increasing and decreasing power)
6. ON/OFF outside zone of rear double cooking zone (2)
7. Automatic cooking timer keys
8. Child lock selection
Electrical insulation
Class I
Fig. 1
