Type xpa explosion-proof panel heater

1
1.0 SPECIAL NOTICES
1.1 The following special notices highlight important
information in the installation and maintenance
sections. Each serves a special purpose and is
displayed in the format shown:
This symbol indicates a potentially hazardous
situation, which, if not avoided, can result in
personal injury or damage to the equipment.
This symbol indicates a potentially hazardous
situation, which, if not avoided, may be a
shock hazard.
This symbol indicates an imminently hazardous
situation, which, if not avoided, could result in
death or serious injury.
2.0 PRE-INSTALLATION
2.1 Initially, inspect the heater for possible damage
due to shipping and handling. Claims for shipping
damages shall be placed with the carrier.
2.2 Check the heater nameplate to ensure that
the heater area classification and temperature
code are suitable for the hazardous area
classification. For details of hazardous
locations with potential for explosion, refer
to the Canadian Electrical Code or National
Electrical Code.
2.3 Check to ensure that the heater voltage is the
same as the supply voltage.
2.4 The heater must be installed by qualified
personnel in strict compliance with national and
local electrical codes.
WARNING
DO NOT CONNECT THE HEATER TO AN
ELECTRICAL SUPPLY VOLTAGE OTHER THAN
THAT SHOWN ON THE PRODUCT NAMEPLATE.
FIGURE 1 - MODEL XPAL/XPAS CONVECTION HEATER
FIGURE 2 - MODEL XPAL/XPAS CONVECTION HEATER
FIGURE 3 - MODEL XPAR CONVECTION HEATER
TYPE XPA EXPLOSION-PROOF
PANEL HEATER
INSTALLATION, OPERATION &
MAINTENANCE INSTRUCTIONS
E-mail: [email protected]
www.ccithermal.com
Date of Issue: March 2014
M11882.Rev.3.00
Printed In Canada
C US
®
ISO 9001
CAUTION
CAUTION
WARNING
