2
Figure 2: Connecting the components to the rear panel (top) and front panel (bottom)
of the Fast Temperature Controller. Components in gray boxes are supplied separately.
FTC REAR PANEL
FTC FRONT PANEL
REMOTE START/
READY SIGNAL CABLE
(for custom applications)
P/N I-25344
POWER SUPPLY
P/N I-25264
TO 110 OR 220 VAC
SUPPLIED
SEPARATELY
SUPPLIED SEPARATELY
COLUMN HARNESS
P/N I-25251-2
FAN HARNESS
P/N I-25345
FAN
COLUMN
USB CABLE
P/N 30-001-06B
CPU
