12
To View or Change the Fan Mode
To view the current fan mode setting:
1. Type FM. The response will be
: fm
2 (or 0, 1, or 3)
2 indicates that the fan is in the default mode 2.
To change the fan mode setting to 0, for example:
1. Type FM=0
2. Verify that the change was made by typing FM. The response should be
: fm
0
To View or Change the Drop Out Temperature
The drop out temperature applies only in mode 2. It is defined as the number of degrees
above the state 1 temperature set point at which the fan will be cut off.
To view the current drop out temperature setting:
1. Type FT. The response will be
: ft
1.000
1.000 indicates a drop out temperature setting of 1°C.
To change the drop out temperature setting to 2 seconds, for example:
1. Type FT=2
2. Verify that the change was made by typing FT. The response should be
: ft
2.000
Fan Installation and Modes
