6
Verifying Column Parameters
Remember that commands can be upper or lower case, and that they must always be
followed by .
To verify that the column parameters have been correctly loaded into the FTC, type
SC (for “show column”). The column parameters should match those on the data
sheet supplied with the column.
: sc
Column id/sn:
12345 Column serial number
Max. temperature:
325 Maximum column temperature in °C
Calibration data:
Temp. Res.
40.00 6.30000 The three resistance vs. temperature
183.00 11.74200 calibration points in °C and ohms
325.00 19.65400
Element equation:
R = 1.31039E1 + 6.44364E-2 * T + 1.74357E-4 * T^2 Resistance equation
Input scaling:
V = -2.82099E-3 + 6.00694E-6 * C - 3.83986E-16 * C^2 Voltage equation
I = 2.59489E-4 + 6.02032E-7 * C - 6.12730E-16 * C^2 Current equation
Verifying Control
1. Read the column temperature by typing RT (for “read temperature”). The
column temperature should be appropriate for its environment. If the temperature
response is not reasonable, recheck the column parameters for errors.
2. Check the column resistance by typing RR (for “read resistance”).
Getting Started
