Valco instruments co., inc – VICI DVSP User Manual
Page 19
REVISIONS
LTR
DESCRIPTION
DATE
APPROVED
A
CHANGE FROM HAND DWG TO CAD
06/15/99
JDURR
PART #
I-PCB21087
I-IC4049
I-RN761-1-220K
I-IC4072
I-LED550-01
I-SW-7103MD
I-R511001
I-CC223-50
I-T09523101
I-T6092007
PARTS LIST
PCB: DIGISWITCH INTERFACE
DESCRIPTION
IC: INVERTING HEX BUFFER
RES NET: 220K, 16 PIN DIP, COMMON
IC: 4 INPUT OR GATE
LED: RED, W/MOUNT, 550-0405 DIALITE
SWITCH: SPDT 7103MD9AB
RES: 1K, 5%, 1/4W
CAP: CERAMIC, .022uF 50V, .250 LEADS
CONN: 10 PIN RT ANGLE MOLEX
CONN: 20 PIN HEADER, RT/ANGLE
DESC
PCB
PCB
Z1
Z2
Z3
L1-L4
S1-S4
R1
C1
C01,2
C03
1 EA
QTY
1 EA
1 EA
1 EA
4 EA
4 EA
1 EA
1 EA
2 EA
1 EA
B
USA PROJECTION
SHEET
SIZE
DRAWING NO.
SCALE
Valco Instruments Co., Inc.
THIS DOCUMENT AND THE INFORMATION WHICH IT CONTAINS SHALL NOT BE USED, EXPLOITED
OR SOLD, AND SHALL NOT BE REVEALED OR DISCLOSED TO OTHERS WITHOUT THE EXPRESSED
WRITTEN PERMISSION OF VALCO. THIS DOCUMENT SHALL REMAIN THE PROPERTY OF VALCO
AND SHALL BE RETURNED UPON DEMAND.
OF
21088
---
PCB ASSY: DIGISWITCH
INTERFACE, TGA-1K
I-21088
APPLIES TO REV B PCB
APPROVED
DRAWN
DESIGNED
CHECKED
FILE NAME
SUB-DIR
DATE
JDURR
06/15/99
21088
\TGA\
FRACTIONS
DEC.
ANGLES
OTHERWISE SPECIFIED
TOLERANCES UNLESS
1/64"
.X.1
.XX.01
1
.XXX.005
63
CO3
C1
INSTALL ON OPPOSITE SIDE
CO2
Z2
Z3
S2
S3
S4
L2
L3
L4
R1
CO1
S1
Z1
L1
17
