Pcb assy: mother bd, Valco instruments co., inc, Four interval dvsp – VICI DVSP User Manual
Page 15
SHEET
DRAWING NO.
OF
21027
B
USA PROJECTION
SIZE
SCALE
FOUR INTERVAL DVSP
Valco Instruments Co., Inc.
THIS DOCUMENT AND THE INFORMATION WHICH IT CONTAINS SHALL NOT BE USED, EXPLOITED
OR SOLD, AND SHALL NOT BE REVEALED OR DISCLOSED TO OTHERS WITHOUT THE EXPRESSED
WRITTEN PERMISSION OF VALCO. THIS DOCUMENT SHALL REMAIN THE PROPERTY OF VALCO
AND SHALL BE RETURNED UPON DEMAND.
PCB ASSY: MOTHER BD
I-21027
REF DWG (21212) SCHEMATIC
SUB-DIR
DATE
1/5/97
\DVSP\
APPROVED
DRAWN
DESIGNED
FRACTIONS
DEC.
ANGLES
OTHERWISE SPECIFIED
TOLERANCES UNLESS
1/64"
.X.1
.XX.01
1
.XXX.005
CHECKED
FILE NAME
63
R.B.D.
21027
NEXT ASSY
B-21143
---
CO13
SC
NUT
MT
PCB: MOTHER BOARD DVSP AW108 REV M
RES NET: 10 K, 16 PIN DIP, COMMON
RES NET: 220 K, 16 PIN DIP, COMMON
IC: 7 BUFFER/LINE DRIVER
IC: 4 INNPUT OR-GATE
CAP: ELECT, 220uF 35V, AXIAL LEAD
CAP: TANTAL, 4.7MF 35V
CAP: CERAMIC, .01uF 1000V
CAP: TANTAL, 1MF 35V
RES: 1.2 K, 5%, 1/4W
RES: 51 K, 5%, 1/4W
CONN: 10 PIN PCB MOLEX
CONN: 10 PIN RT ANGLE MOLEX
CONN: GS 5/10 WEIDMULLER #4596-6
CONN: GS 5/4 WEIDMULLER 4382-6
CONN: GS 5/2 WEIDMULLER #4109-6
IC: VOLTAGE REGULATOR, 12V, T0220
DESCRIPTION
DES
PARTS LIST
SO1-6
INSTALL ON
BOTTOM OF PCB
I-PCB21024
I-RN761-1-10K
I-RN761-1-220K
I-IC2004
I-IC4072
I-CE227-35AL
I-CT475-35
I-CC103-1K
I-CT105-35
I-R511201
I-R515102
I-T09523103
I-T09523101
I-T4596-6
I-T4382-6
I-T4109-6
I-IC7812
1
1
VALCO #
RN1
PCB
CO10-12
CO13
REG
CO1-4
CO5-7
CO8,9
R1-4
R5
Z4
C3
C4,5
C6
C1,2
Z2
RN2
1
4
1
4
3
2
3
1
4
1
6
5
1
6
2
2
2
2
2
I-D-VE28
I-SW-7103MD
I-SW-MTM106
I-LED550-01
I-RY-NC2DPDC12
I-X-SSC-16-1
HWSO-4639B
HW-607
HWSC-PL4-4
HWNUT-HEX#4
HWW-N#4
HW-MICA
RECTIFIER BRIDGE
SWITCH: SPDT 7103MD9AB SPDT-RPC-C-P-S
SWITCH: TOGGLE SPDT-RPC-N-P-S
LED: RED, WITH MOUNT 550-0405 DIALIGHT
RELAY: AROMAT 12V DC
TRANSFORMER 16 VCT .6 AMP 120V
STANDOFF: #4-40 X .1875 SWAGE THREADED
MALE TABS
SCREW,PLMS: 4-40 X 1/4 LG PH,SS
NUT, HEX: #4-40 UNC, STAINLESS
WASHER: SHOULDER, #4 HHS-2661 NYLON
MICA INSULATORS #4671
1
1
1
1
1
2
1
2
QTY
S5
MT
NW
MICA
SC
NUT
SO1-6
T1
L1-6
S1-4
RA
RLY1-5
S5
REVISIONS
DESCRIPTION
DATE
INITIATED
MOVE S1-S4 & Z3 ADD C4-6 MOVE INPUT POWER TERM.
11/16/82
-
ECN #4027 REDRAWN IN ACAD UPDATE BOM
01/07/98
J DURR
LTR
N
P
CO10
CO8
CO9
CO11
RLY3
RLY2
RLY1
RLY4
RLY5
CO12
C4
C5
SC
MT
NUT
PCB
Z2
C3
C2
C1
CO4
CO3
INSTALLED ON BACK
OF BOARD
CO7
T1
RA
R2
R3
R4
L6
L5
R1
R5
RN1
C6
CO1
CO2
REG
A
A
S4
L3
Z4
INSTALL MICA INSULATOR
UNDER S3 AND S4
CO5
CO6
S3
RN2
L2
S2
L1
VIEW A-A
