Trebor SS95 Surge Suppressor - Manual (Page 4)

1.2.a Port Mounted
(21.08)
8.30
AIR SUPPLY AIR SUPPLY
CONNECTION
3/8" TUBE 3/8" TUBE
REMOTE EXHAUST REMOTE EXHAUST
CONNECTION
1/8" TUBE 1/8" TUBE
(13.89)
5.47
(20.32)
8.00
IN
(CM)
MTD0375
Figure 1-1
Pump Assembled Height: IN (CM)
MEGA 960 15.06 (38.25)
MAXIM 25 12.22 (31.04)
MAXIM 50 13.97 (35.48)
1.2.b Inline, Internal Ports
PAGE 4 SS95 SURGE OPERATION / MAINTENANCE MANUAL
(10.67)
4.20
(20.32)
8.00
(18.06)
7.11
AIR SUPPLY AIR SUPPLY
CONNECTION
3/8" TUBE 3/8" TUBE
REMOTE EXHAUST REMOTE EXHAUST
CONNECTION
1/8" TUBE 1/8" TUBE
FLUID PORT FLUID PORT
FITTINGS (INCLUDED FITTINGS (INCLUDED
WITH TEE OPTION) WITH TEE OPTION)
(11.35)
4.47
(5.23)
2.06
(6.99)
2.75
(3.07)
1.21
(5.79)
2.28
(9.53)
3.75
IN
(CM)
MTD0376
CL
