3 START-UP
• Pump air supply pressure should be regulated.
• Open the fluid suction (IN) line valve, if necessary.
• Open the fluid discharge (OUT) line valve, if necessary.
• Start with air regulator at low pressure setting. Increase or decrease air
pressure to attain desired flow, up to 80 psig (4.1 bar).
• Table 1: Consumption / Efficiency can be used to determine approximate air
consumption.
• Refer to Troubleshooting, Section 5, if pump fails to start.
ATTENTION: Prolonged periods of dry running (>5 minutes) will damage critical
internal pump parts.
CAUTION: When handling potentially dangerous fluids under pressure,
the pump and its fittings should be placed in an enclosure.
3.1 HIGH TEMPERATURE OPERATION
Pump operation at temperatures above 60°C requires periodic tightening of the
tie bolt nuts. The frequency of this procedure is best established by the user.
3.2 PERFORMANCE CHARTS
Pumping capacity is a function of air supply pressure and volume, suction head,
suction line restrictions, discharge head, discharge line restriction, and fluid
specific gravity and viscosity.
Air Supply
Pressure
(PSIG)
Discharge
Fluid
Pressure
(PSIG)
Air
Used
(SCFM)
Cycles
Per
Minute
Displacement
IN
3
Per
Cycle (Max)
25 2 7.4 108 35
30 3 8.9 116 33
30 10 8.2 100 32
40 5 11.6 152 29
40 20 11.1 108 31
50 10 14.4 156 28
50 30 12.2 104 30
60 20 16.6 156 26
60 50 12.6 94 29
Table 1: Consumption / Efficiency
NOTE: Specification to be used to size regulators and control valves.
