4.5 PARTS LIST
ILL
NO PART NO QTY DESCRIPTION PM
YEAR #
MATERIAL
1 L0154 2 Check Bore Cap PTFE
2 L0163 2 Seal, Check Port 1 PTFE
3 L0096 2 Discharge Sleeve PTFE
4 98002740 4 Check Ball 1 PTFE
5 98002261 4 O-Ring 1 PTFE
6 L0191 4 Check Seat Wear Ring PTFE
7 L0193 2 Suction Sleeve PTFE
8 L0190 1 Body PTFE
9 L0192 1 Shaft Bushing 1 PTFE
10 L0195 1 Locking Ring PTFE
11 L0123 1 Main Shaft 2 PFA
12 1900B0070 2 Push Plate PTFE
13 1900B0023 2 Diaphragm Set 1 PFA
14 98001585 2 Main Seal 1 Viton
15 L0185 2 Head PP
16 L0184 8 Spacer, Tie Bolt PP
17 1900B0027-01 8 Tie Bolt Assembly SS316, PFA
18 L0100 16 Tie Bolt Cap 1 LDPE
19 98003047 2 Quick Exhaust Seal 1 Viton
20 1900B0016 2 Quick Exhaust Port UHMW
21 L0119 2 Assembly, Muffler 1 PP
22 98002243 10 Plug, 3/8 NPT PE
23 98003514 2 Fitting, Air PP
24 L0140 8 Bushing NPRN,EPDM
25 1900A0028-01 8 Tie Bolt Washer SS316
26 98002341 8 Nut, Flange, SS, 1/4 - 20 SS18-8
27 98001418 4 Insert SS18-8
28 1900B0033 1 Pump Base PP
29 98001093 4 Washer SS18-8
30 98001375 4 Screw SS18-8
31 98001108 4 Cap, Blue LDPE
32 98003755 1 Screw, Lock Ring PTFE
33 98003769 2 Screw, Push Plate PTFE
4.6 CLEAN-UP
To help remove potentially dangerous chemicals, the pump can be flushed with
DI water or disassembled and thoroughly cleaned.
4.7 DISASSEMBLY
During the life of the pump it will be necessary to perform certain preventative
maintenance procedures to ensure its continued high performance. This section
and the next (4.8 Assembly) are provided for the user’s convenience in
disassembly and re-assembly in performing these procedures.
• Thoroughly clean/flush the pump using DI water (Refer to Section 4.6 Clean-
Up).
• Remove tie bolt caps from the slave head.
• Remove nuts from the tie bolts (Slave Head side). Leave tie bolts in place.
• Lay the pump on its side with slave side up.
• Lift off the slave head.
• Remove the main seal and diaphragms.
MEGA 960E PUMP OPERATION / MAINTENANCE MANUAL PAGE 15
