MEGA 120D PUMP OPERATION / MAINTENANCE MANUAL
PAGE 15
4.5 PARTS LIST
ILL
NO
PART NO
QTY
DESCRIPTION
PM
YEAR #
MATERIAL
1
BL006
2
Check Bore Plug
PTFE
2
BL007
2
Gasket Seal, Check Port
1
PTFE
3
BL004
2
Discharge Sleeve
PTFE
4
98004255
4
Check Ball
1
PTFE
5
98004258
4
O-Ring
1
PTFE
6
BL003
2
Suction Sleeve
PTFE
7
BL002
2
Suction Seat
PTFE
8
BL001
1
Body
PTFE
9
BL012
1
Shaft Bushing
1
PTFE
10
L0195
1
Locking Ring
PTFE
11
BL011
1
Main Shaft
2
PFA
12
1900B0070
2
Push Plate
PTFE
13
1900B0023
2
Diaphragm Set
1
PFA
14
98001585
2
Main Seal
1
Viton
15
L0141-01
1
Master Head
PP
16
BL014
8
Tie Bolt Assembly
SS316, PFA
17
L0100
16
Tie Bolt Cap
1
LDPE
18
W0114
2
Cap, Pilot
PP
19
W0116
2
Seal, Pilot Cap
PTFE
20
W0123
2
Assembly, Pilot Valve, Wear Resistant
Peek, PTFE,
PPS, Viton
21
W0117
2
Seal, Pilot Sleeve
PTFE
22
AM040
2
Leak Port Cap
PP
23
L0167
2
Leak Port Seal
PTFE
24
98003047
2
Quick Exhaust Seal
1
Viton
25
1900B0016
2
Quick Exhaust Port
UHMW
26
L0119
2
Muffler Assembly
1
PP
27
98003080
2
Plug, Remote Exhaust
PE
28
AK058
1
NM Sleeve Assembly
Ceramic,
PTFE
29
L0105
1
Adapter, Detent
PP
30
L0131
1
Assembly, Spool External, High Load
Ceramic,
PEEK,
Torlon
30A
L0197
2
Leg, Detent
1
Torlon
30B
L0145
1
Ring, Detent, High Load
1
PEEK
31
L0113
1
Seal, Detent Cap
PTFE
32
L0104
1
Cap, Detent External
PP
33
L0139-01
1
Slave Head
PP
34
L0140
8
Bushing
NPRN,EPD
M
35
1900A0028-01
8
Tie Bolt Washer
SS316
36
98002341
8
Nut, Flange, SS, 1/4 - 20
SS18-8
37
98002620
1
Label Cap
LDPE
38
98001418
4
Insert
SS18-8
39
BL017
1
Pump Base
PP
40
98001093
4
Washer
SS18-8
41
98001375
4
Screw
SS18-8
42
98001108
4
Cap, Blue
LDPE
43
1900A0024
2
Main Transfer Tube
PFA
44
98002240
2
O-Ring
1
Viton
45
BL022
1
Shuttle Transfer Tube
PFA
46
98002303
4
O-Ring
1
Viton
47
98003755
1
Screw, Locking Ring
PTFE
48
98003769
2
Screw, Push Plate
PTFE
