MEGA 120D PUMP OPERATION / MAINTENANCE MANUAL
PAGE 13
4.2 RECOMMENDED SPARE PARTS
KR120D-00-A Spares Rebuild Kit, which includes:
Part No
Qty
Description
KD120-00-A
1
Diaphragm Kit*
Includes:
(2)
(2)
1900B0023
98001585
Diaphragm Set
FKM O-Ring
KM120D-00-C
1
Maintenance Kit
Includes:
(2)
(2)
(2)
(2)
(2)
(1)
1900B0016
98002987
98003047
L0119
L0197
L0145
Quick Exhaust Port
Pilot Button
Quick Exhaust Seal
Muffler Assembly
Detent Leg
Detent Ring
98001108
4
Cap, Blue
98002240
2
FKM O-Ring
98004258
4
O-Ring, PTFE
98002303
4
FKM O-Ring
98004255
4
Check Ball
BL002
2
Suction Seat
BL007
2
Check Port Gasket
BL009
2
Fluid Port Gaskets
BL012
1
Shaft Bushing
L0100
16
Tie Bolt Cap
Kits are available with FFKM o-ring in place of FKM o-rings. Contact your Trebor
representative for more information.
In critical applications, a spare pump is recommended to minimize potential down time.
4.3 TOOLS
The following tool kit is recommended as standard service equipment.
KT120-00-A Tool Kit, which includes:
Part No
Qty
Description
98001230
1
5/32” Allen Wrench
98002136
2
7/16” Nut Driver
98002859
1
7/16” Socket
98003150
1
Tool Case
98003305
1
Drive Handle
T0172
1
Check Sleeve Insertion Tool
T0173
1
Check Sleeve Removal Tool
T0146
1
¾” Pin Tool
T0147
1
1” Pin Tool
T0148
1
½” Pin Tool
T0159
1
2” Pin Tool
T0144
1
Cleaning Tool
T000A0021
1
Shaft Bullet
