Setting the Time
Step 1: Use the Menu button to select the Time menu. The
current time and day displays. If the clock has not been
set, the time will flash.
Step 2: Use the Item button to advance to the next item. If
your installer has selected Daylight Savings Time the date
is displayed. If the date has not been set, it will flash. If your
installer has not selected Daylight Savings Time, the date
will not be displayed.
Step 3: Use the Item button to advance to the next item.
The minutes begin to flash. Use the Up or Down button to
set the minutes.
Step 4: Use the item button to advance to the next item.
The hours begin to flash. Use the Up or Down button to
set the hour.
The Date is displayed in sections starting with the Month,
followed by the day of the month, then year.
Step 5: Use the Item button to advance to the next item.
The day begins to flash. Use the Up or Down button to set
the day.
If your installer has selected Daylight Savings Time
then continue with Steps 6, 7, and 8.
Step 6: Use the Item button to advance to the next item.
The month can now be set. The display will toggle between
“Month” and “JAN” every two seconds. Use the Up or Down
button to set the month.
Step 7: Use the Item button to advance to the next item.
The Day can now be set. The display will toggle between
“Day” and “01” every two seconds. Use the Up or Down
button to set the day of the month.
Step 8: Use the Item button to advance to the next item.
The Year can now be set. The display with toggle between
“Year” and “2007” every two seconds. Use the Up or Down
button to set the year.
Selecting a Schedule
During installation, your installer will have selected a
schedule for your thermostats to follow.
To view which schedules have been selected to operate:
1.
1. Use the Menu button to navigate through the timer and
view which schedules have been turned ON. Schedules
that are not turned on will not be viewable. You can
have a maximum of 4 schedules.
2. 2. Use the Item button to navigate through each schedule
menu to view the settings of the selected schedule.
Note: For instructions on how to change the number of
available schedules, see the Data Brochure D 033. An
electronic version of the D 033 is available on the tekmar
website: www.tekmarcontrols.com.
