9
QUICK START GUIDE
This guide is designed to get you up and running in a matter of moments. To
get the most out of this advanced scouting tools, please read the manual
thoroughly before operating the camera. If you would like to modify any of
the factory Default Settings, except for the Time & Date, please see manual for
instructions.
FACTORY DEFAULT SETTINGS:
Time Out: 30 Sec Burst Mode: 1 Still Image (1.3Mp Resolution)
Operation Mode: PIR Video Mode: 10 Seconds (VGA Resolution)
Time lapse setting: 18:00‐8:00 Next day
CAMERA SETUP:
1. Install 8 “AA” cell batteries in correct polarity (+/‐) as indicated in battery
compartment.
2. Insert SD card into the camera.
3. Turn power on to adjust Time and Date.
SET TIME AND DATE:
1. Switch the camera to the ON position.
2. Press the [MENU] button to enter menu settings screen.
3. Press the [UP] or [DN] button until the word PIR blinking.
4. Press the [OK] button to confirm.
5. Press the [UP] or [DN] button to scroll through different setting modes
until the word TIME blinking.
6. Press the [OK] button to choose the Time settings.
7. Press the [UP] or [DN] button to adjust the Minute setting and press [OK]
to confirm and move to the Hour setting.
8. Repeat to set Hour and then press [OK] to confirm and move to Date.
9. Adjust the Month, Day and Year by using [UP] or [DN] button. Each time
you finish an adjustment you must press the [OK] button to confirm and
move to the next field for adjustment.
10.Once done, the word ‐ dEL – will be blinking.
11. Press the [MENU] button to exit and start using.
WWW.STEALTHCAM.NET
Toll Free 877-269-8490
10
BATTERY AND MEMORY INSTALLATION
Your Stealth Cam Advanced Digital Scouting Camera is designed to
operate using two different types of battery power options.
Batteries “AA” cell
The internal battery compartment accepts 8 “AA” cell batteries. Be
sure to use high quality brand name alkaline batteries. Install
batteries with correct polarity (+/‐) as noted inside the battery
compartment.
12V Lead Acid external battery
The camera is equipped with an external power jack designed to
accept a barrel plug cable attached to a sealed lead acid battery. (Sold
separately). Battery cable and complete 12V Lead Acid battery kits are
available wherever Stealth Cam scouting cameras are sold or call toll
free 877‐269‐8490. Only Stealth Cam external battery accessories are
recommended.
WARNING: Do not use different Voltage lead acid battery other than
the one specified in this section. Doing so will damage the camera
and will void the warranty.
WARNING: ALWAYS have the camera in the OFF position when
installing or removing batteries and memory card. Removing batteries
or memory card while the camera is ON may damage the camera.
WWW.STEALTHCAM.NET
Toll Free 877-269-8490
11
• Make sure camera is in the OFF position.
• Insert the external battery barrel plug into the DC 12V jack on the
bottom of camera housing.
• Turn the camera power on.
NOTE: Please make sure the voltage and polarity (+/‐) are correct
before connection. Incorrect voltage or polarity (+/‐) will damage the
camera. When both internal and external batteries are connected,
the camera will draw power from the higher voltage source first.
Memory Options
The camera is also equipped with an expandable media card slot
capable of accepting up to 16GB SD card (sold separately). The front
counter display will show the number of images stored on the SD card.
If no SD card is inserted the front counter display will show “NOSd”.
WARNING: The above camera will not accept any High Speed
memory cards. Common verbiage that will indicate High Speed
includes but is not limited to: Extreme, Ultra, Optima, Micro,
Platinum, Store and Shoot.
WWW.STEALTHCAM.NET
Toll Free 877-269-8490
12
Inserting SD memory card
NOTE: Make sure camera is in the OFF position whenever adding or
removing memory.
• Insert SD memory card in to the SD card slot completely and in the
correct direction as shown by the sticker located at the side of the
housing.
• To remove the SD memory card, depress the SD card and pull out
the card gently.
• SD cards must be clean (no images from other sources). If you are
using the SD card from other cameras, please make sure to format
the SD card in your computer prior to use in your camera. New
cards are good to use straight from the package.
FORMAT – Definition: When you format a SD memory card, the
operating system erases all information and files on the card. Then it
creates an internal address tables that it later uses to locate
information and files. Formatting also removes all Hidden System files
as well. Basically it cleans your SD memory card just like if it was brand
new. Please make sure to follow the guidelines listed below:
SD Card size: 2Gb or below, format using File System type “FAT”.
SD Card size: 4GB or above, format using File System type “FAT32”.
Do not use File System type “NTFS” or “exFAT”, these formats are not
supported.
