Chamberlain 5100-2K User Manual
Garage door opener owner’s manual

The Chamberlain Group, Inc.
A DUCHOSSOIS ENTERPRISE
845 Larch Avenue
Elmhurst, Illinois 60126-1196
Cover Art - Liftmaster Combined Manual USA
Models 5100, 4100, 4100-2, 710-2, 2100, 1100
5/21/92
Model 5100 -2K - 1/2 HP
Series 4100 - 1/2HP
Series 710 WHC - 1/2HP
Series 2100 -1/3HP
Series 1100-1/4HP
Complies with UL 324
Regulations effective
January 1, 1993.
Garage Door Opener
Owner’s Manual
For Residential Use Only
Model 5100-2K – 1/2HP
■
Please read this manual and the enclosed safety materials carefully!
■
Fasten the manual near the garage door after installation.
■
The door WILL NOT CLOSE unless the Protector System
®
is connected and
properly aligned.
■
Periodic checks of the opener are required to ensure safe operation.
■
The model number label is located on the front end panel of your opener.
®
®
®
®
