Rite-Ride 2171 - Manual (Page 2)

HOLES
TO
BE DRILLED 7/16"
REAR
WHEEL
2171
AIR
SPRING
DISK
LOWER
BRACKET
3/8” -16 FLANGED
HEX BOLT
3/8" -16 x 3-1/2"
CARRIAGE
BOLT
N
OTE
: Both illustrations are of the
right, or passenger’s side of the vehicle.
Reverse any orientations when
assembling and installing the left, or
driver’s side of the vehicle.
KIT TO FRAME ASSEMBLY
UPPER
BRACKET
K
I
T
A
S
S
E
M
B
L
Y
3/8" -16 x 1-1/2"
HEX BOLT
3/8" -16 x 1-1/2"
HEX BOLT
3/8" -16 FLANGED
LOCK NUT
BRACKET STRAP
AXLE
LEAF
STACK
AIR SPRING
ASSEMBLY
FIGURE "A"
FLAT
WASHER
3/8" -16
FLANGED
LOCK NUT
FLAT
WASHER
BARBED
FITTING
3/4” JAM NUT
3/4” STAR
WASHER
FRAME
AIR
LINE
LARGE FLAT
WASHER
LARGE FLAT
WASHER
