ELBOW
FITTING

AIR SPRING

3/8-16” x 3/4”
FLANGE LOCK
BOLT

5/16”-24
FLANGE LOCK
NUT

5/16”-24 x 4”
U-BOLT

AXLE

LEAF

SPRING

LOWER

BRACKET

5/16”-18 x 4”

BAIL CLAMP

FRAME

5/16”-18

FLANGE NUT

UPPER

BRACKET

5/16”-18
FLANGE NUT

3/8”-16

FLANGE NUT

REAR

WHEEL

1130

NOTE: The illustrations are of
the left, or driver’s side, of the
vehicle. Follow the same procedure
for the right, or passenger’s, side.

FIGURE “A”
