Revel Concerta IW65/IW80 & IC65/IC80/IC6T2
Owner’s Manual
Specification
IW65
IW80
IC65
IC80
IC6T2
Frequency Response
50Hz to 40kHz, ±3dB 40 Hz to 40 kHz, ±3dB 50Hz to 40kHz, ±3dB
45Hz to 40kHz, ±3dB
55 Hz to 22 kHz, ±3dB
(2
π anechoic)
Recommended Amplifier
10 – 125 Watts
10 – 135 Watts
10 – 125 Watts
10 – 135 Watts
10 – 125 Watts
Power Range
(Total)
Sensitivity
89dB
89dB
89dB
89dB
88dB
(2.83V, 2
π anechoic)
(Both channels driven)
Nominal Impedance
8 Ohms
8 Ohms
8 Ohms
8 Ohms
6 Ohms
Crossover Frequency
3,000Hz; 24dB/Octave 2,400Hz; 18dB/Octave 2,500Hz; 18dB/Octave
2,500Hz; 18dB/Octave
2000Hz; 24dB/Octave
Low-Frequency Driver
6-1/2" (165mm) Micro
8" (200mm) Micro
6-1/2" (165mm) Micro
8" (200mm) Micro
6-1/2" (165mm) Micro
Ceramic Composite
Ceramic Composite
Ceramic Composite
Ceramic Composite
Ceramic Composite
(MCC) cone
(MCC) cone
(MCC) cone
(MCC) cone
(MCC) cone
High-Frequency Driver
1" (25mm) Micro
1" (25mm) Micro
1" (25mm) Micro
1" (25mm) Micro
Dual 3/4" (19mm) Micro
Ceramic Composite
Ceramic Composite
Ceramic Composite
Ceramic Composite
Ceramic Composite
(MCC) dome
(MCC) dome
(MCC) dome
(MCC) dome
(MCC) domes
External Dimensions
8-1/2" x 11"
10-1/4" x 13-7/16"
Diameter: 9-1/4"
Diameter: 10-7/8"
Diameter: 9-1/4"
(W x H)
(216mm x 280mm)
(259mm x 341mm)
(235mm)
(275mm)
(235mm)
Mounting Cutout Size
7" x 9-1/2"
8-3/4" x 11-3/4"
Diameter: 7-7/8"
Diameter: 9-1/2"
Diameter: 7-7/8"
(W x H)
(178mm x 241mm)
(221mm x 297mm)
(200mm)
(241mm)
(200 mm)
Mounting Depth
3-1/2" (89mm)
4" (102mm)
4-1/8" (104mm)
4-3/4" (121mm)
4-1/8" (104mm)
Recommended Optimum
Infinite Baffle
88 liters
Infinite Baffle
88 liters
Infinite Baffle
Enclosure Volume
(full stud bay)
(full stud bay)
(full stud bay)
Weight (Net)
3.5 lb (1.6kg)
5.9 lb (2.7kg)
3.5 lb (1.6kg)
5.8 lb (2.6kg)
3.5 lb (1.6kg)
SPECIFICATIONS
Specifications are subject to change without notice.
Declaration of Conformity
We,
Harman Consumer Group, Inc.
2, route de Tours
72500 Château du Loir
France
declare in own responsibility that the products described
in this owner’s manual are in compliance with technical
standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
Laurent Rault
Harman Consumer Group, Inc.
Château du Loir, France 7/08
