ENGLISH
27
REAR PANEL
FRONT SIDE
1. DESIGNATIONS
1. Microphone Volume
2. 2-band Equalizer for Microphone
3. Microphone/Talkover Activation Switch
4. Channel Volume
5. Channel 3-band Equalizer
6. Channel Signal Input Selector
7. Master Volume
8. Cue Volume
9. Effect Monitoring Function
10. Cue/Master Switch
11.
CueMix Fader (CUE/Master)
12. Modulation LEDs (CUE/Master)
13.
LCD Info Display
14. Effect Selection Switch
15. Crossfader Effect Switch
16. Effect Channel Assignment Switch
17.
Linefaders for Channels A + B
18. Y Parameter Effect Fader
19.
FX ON/OFF Button
20. Crossfader Effect Assignment LEDs
21. Crossfader
22. Crossfader Effect Selection Buttons a, b, c
23. TAP/BPM Button
24. Beat Assignment Buttons for DSP Effect Unit
25. X Parameter Encoder
48. CUE/Monitoring Function
49. Input Signal Selection Display
27
26
38
39 40 41 42 43 40 44
45 46 37
47
51
36 35 34 33 32 31
29
30
29
30
31
50 28
