—30—
DETAILED COOLING CAPACITIES* Continued
See notes on page 32.
EVAP
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW** Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
552AN048-F Outdoor Section With CK5A/CK5BA060 Indoor Section
1400
72 53.9 26.9 3.58 51.7 26.2 3.98 49.2 25.4 4.42 46.4 24.5 4.90 43.6 23.6 5.45 40.3 22.5 6.07
67 50.4 35.1 3.52 48.0 34.2 3.90 45.4 33.2 4.34 42.8 32.3 4.82 39.5 31.1 5.35 34.7 29.2 5.90
63†† 47.3 34.5 3.48 44.9 33.5 3.85 42.4 32.4 4.28 38.8 30.9 4.73 34.8 29.2 5.22 30.0 27.2 5.75
62 46.7 43.1 3.46 44.4 42.0 3.84 41.7 40.7 4.26 39.0 39.0 4.73 36.0 36.0 5.25 32.3 32.3 5.82
57 45.4 45.4 3.44 42.8 42.8 3.82 40.1 40.1 4.23 38.4 38.4 4.72 35.5 35.5 5.24 32.3 32.3 5.83
1600
72 54.1 27.7 3.66 52.0 27.0 4.06 49.6 26.4 4.50 47.1 25.7 5.01 44.2 24.9 5.56 40.6 23.8 6.18
67 50.8 36.8 3.60 48.6 36.2 3.99 46.0 35.4 4.43 43.4 34.5 4.92 40.1 33.4 5.45 35.2 31.5 6.01
63†† 47.9 36.4 3.55 45.7 35.6 3.95 43.1 34.5 4.37 39.3 33.0 4.82 35.2 31.3 5.31 30.3 29.2 5.84
62 47.7 46.2 3.56 45.4 45.0 3.94 43.0 43.0 4.37 40.4 40.4 4.85 37.2 37.2 5.37 33.3 33.3 5.95
57 47.4 47.4 3.55 44.9 44.9 3.93 43.3 43.3 4.38 41.0 41.0 4.86 37.8 37.8 5.38 34.1 34.1 5.96
1800
72 54.7 28.7 3.75 52.6 28.1 4.15 50.3 27.7 4.60 47.4 26.8 5.09 44.4 26.1 5.64 40.9 25.0 6.28
67 51.3 38.6 3.69 49.1 38.2 4.08 46.5 37.4 4.51 43.8 36.6 5.00 40.6 35.5 5.55 35.7 33.7 6.11
63†† 48.4 38.2 3.64 46.2 37.6 4.03 43.6 36.6 4.46 40.1 35.1 4.92 35.6 33.2 5.40 30.8 30.8 5.94
62 48.7 48.6 3.65 46.4 46.4 4.03 44.4 44.4 4.47 42.2 42.2 4.97 38.5 38.5 5.49 34.4 34.4 6.07
57 48.5 48.5 3.64 46.4 46.4 4.03 44.3 44.3 4.47 42.2 42.2 4.97 39.6 39.6 5.51 35.2 35.2 6.09
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
CC5A/CD5AA 060 0.98 1.00 CE3AA 048 0.97 0.95
CC5A/CD5AC 048 0.96 0.99 060 0.98 0.93
CC5A/CD5AW 048 0.98 1.00 CK3BA 048 0.97 0.95
060 1.01 1.02 CK5A/CK5BA 048 0.97 0.95
CD5AA 048 0.98 1.00 CK5A/CK5BT 048 0.97 0.95
CE3AA 048 0.98 0.99 CK5PA 048 0.97 0.95
060 1.00 1.00 CK5PT 048 0.97 0.95
CF5AA 048 0.96 0.98 COILS + 315(A,J)AV066110 VARIABLE SPEED FURNACE
CK3BA 048 0.98 1.00 CC5A/CD5AA 060 0.98 0.94
060 1.00 1.00 CC5A/CD5AC 048 0.96 0.93
CK5A/CK5BA 048 0.98 1.00 CC5A/CD5AW 048 0.97 0.93
060 1.00 1.00 CD5AA 048 0.97 0.93
CK5A/CK5BT 048 0.98 1.00 CD5PX 060 0.99 0.92
060 1.00 1.00 CE3AA 048 0.97 0.93
CK5A/CK5BW 048 0.98 1.00 060 0.98 0.92
CK5A/CK5BX 060 1.01 1.00 CK3BA 048 0.97 0.93
CK5PA 048 0.98 1.00 060 0.98 0.92
060 1.00 1.00 CK5A/CK5BA 048 0.97 0.93
CK5PT 048 0.98 1.00 060 0.98 0.92
060 1.00 1.00 CK5A/CK5BT 048 0.97 0.93
CK5PW 048 0.98 1.00 060 0.98 0.92
CK5PX 060 1.01 1.00 CK5A/CK5BW 0.48 0.97 0.93
F(A,B)4(A,B)N(F,B,C) 048 0.98 1.01 CK5A/CK5BX 060 0.99 0.91
060 1.00 1.03 CK5PA 048 0.97 0.93
FB4(A,B)NB 070 1.01 1.01 060 0.98 0.92
FC4(B,C)N(F,B) 048 0.97 1.01 CK5PT 048 0.97 0.93
060 0.98 1.02 060 0.98 0.92
FC4(B,C)NB 054 0.98 0.98 CK5PW 048 0.97 0.93
070 1.00 1.01 CK5PX 060 0.99 0.91
FG3AAA 048 0.96 0.98 COILS + 315(A,J)AV066135 VARIABLE SPEED FURNACE
060 0.98 0.99 CC5A/CD5AA 060 0.97 0.93
FK4(C,D)NB 006 1.00 0.92 CC5A/CD5AC 048 0.96 0.93
FK4(C,D)NF 005 0.98 0.92 CC5A/CD5AW 048 0.97 0.94
FV4(A,B)NB 006 1.00 0.92 060 0.99 0.93
FV4(A,B)NF 005 0.98 0.92 CD5AA 048 0.97 0.93
FX4(A,B)NB 060 0.99 1.00 CE3AA 048 0.97 0.94
FX4(A,B)NF 048 0.98 1.00 060 0.98 0.92
COILS + 315(A,J)AV048090 VARIABLE SPEED FURNACE CK3BA 048 0.97 0.94
CC5A/CD5AC 048 0.95 0.94 060 0.98 0.92
CD5AA 048 0.97 0.95 CK5A/CK5BA 048 0.97 0.94
— — — 060 0.98 0.92
