DETAILED COOLING CAPACITIES* continued
See notes on page 32.
EVAP
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
75
85
95
105
115
125
CFM
EWB
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Capacity
MBtuh†
Total
Sys
kW**
Total Sens‡
Total Sens‡
Total Sens‡
Total Sens‡
Total Sens‡
Total Sens‡
552AN024-G Outdoor Section With CK5A/CK5BA030 Indoor Section continued
700
57
22.07
22.07
1.63
21.10
21.10
1.84
20.07
20.07
2.08
18.98
18.98
2.33
17.84
17.84
2.61
16.57
16.57
2.91
62
22.81
20.78
1.63
21.49
20.17
1.85
20.24
19.57
2.08
18.95
18.95
2.33
17.84
17.84
2.61
16.57
16.57
2.91
67
25.23
17.55
1.64
23.98
17.11
1.86
22.53
16.54
2.11
21.03
15.93
2.38
19.47
15.30
2.66
17.81
14.65
2.95
72
26.57
13.74
1.66
26.09
13.70
1.88
24.99
13.36
2.13
23.58
12.86
2.40
22.00
12.28
2.68
20.25
11.66
2.99
800
57
23.21
23.21
1.66
22.07
22.07
1.89
20.97
20.97
2.13
19.88
19.88
2.40
18.65
18.65
2.67
17.33
17.33
2.98
62
23.51
22.30
1.67
22.14
21.70
1.89
20.97
20.97
2.13
19.88
19.88
2.40
18.64
18.64
2.67
17.35
17.35
2.98
67
25.61
18.42
1.68
24.47
18.13
1.90
23.00
17.62
2.15
21.48
17.04
2.42
19.84
16.41
2.71
18.19
15.76
3.01
72
26.62
14.00
1.70
26.29
14.12
1.92
25.29
13.88
2.17
23.88
13.42
2.44
22.29
12.88
2.72
20.51
12.27
3.03
900
57
24.04
24.04
1.70
22.93
22.93
1.93
21.80
21.80
2.19
20.58
20.58
2.45
19.32
19.32
2.73
17.99
17.99
3.05
62
24.08
23.62
1.71
22.93
22.93
1.93
21.79
21.79
2.19
20.57
20.57
2.46
19.32
19.32
2.73
17.99
17.99
3.05
67
25.80
19.11
1.72
24.77
19.02
1.94
23.33
18.61
2.19
21.81
18.07
2.45
20.21
17.48
2.75
18.46
16.79
3.05
72
26.66
14.25
1.73
26.38
14.46
1.96
25.42
14.30
2.21
24.05
13.90
2.48
22.47
13.40
2.76
20.68
12.80
3.07
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section
Size
Cooling
Indoor
Section
Size
Cooling
Capacity
Power
Capacity
Power
COILS + 355MAV042040 VARIABLE SPEED FURNACE
CK5PW
024
0.97
0.89
CE3AA
024
0.97
0.90
030
1.01
0.92
030
0.98
0.90
COILS + 355MAV060080 VARIABLE SPEED FURNACE
COILS + 355MAV042060 VARIABLE SPEED FURNACE
CC5A/CD5AW
024
0.97
0.90
CC5A/CD5AA
024
0.97
0.90
030
0.98
0.90
030
0.98
0.90
CE3AA
024
0.97
0.90
CC5A/CD5AW
024
0.97
0.90
030
0.98
0.89
030
0.98
0.90
CK3BA
024
0.97
0.88
CE3AA
024
0.97
0.89
030
0.98
0.89
030
0.98
0.89
CK5A/CK5BW
024
0.97
0.89
CK3BA
024
0.97
0.88
030
0.98
0.89
030
0.98
0.89
CK5PW
024
0.97
0.89
CK5A/CK5BA
024
0.97
0.89
030
0.98
0.89
030
0.98
0.89
COILS + 355MAV060100 VARIABLE SPEED FURNACE
CK5A/CK5BW
024
0.97
0.89
CC5A/CD5AW
024
0.97
0.90
030
0.98
0.89
030
0.98
0.90
CK5PA
024
0.97
0.89
CE3AA
024
0.97
0.89
030
0.98
0.90
030
0.98
0.89
CK5PW
024
0.97
0.89
CK3BA
024
0.97
0.88
030
0.98
0.89
030
0.98
0.89
COILS + 355MAV042080 VARIABLE SPEED FURNACE
CK5A/CK5BW
024
0.97
0.89
CC5A/CD5AW
024
0.97
0.90
030
0.98
0.89
030
0.98
0.90
CK5PW
024
0.97
0.89
CE3AA
024
0.97
0.90
030
0.98
0.89
030
0.98
0.90
COILS + 355MAV060120 VARIABLE SPEED FURNACE
CK3BA
024
0.97
0.88
CE3AA
024
0.97
0.90
030
0.98
0.89
030
0.98
0.90
CK5A/CK5BW
024
0.97
0.89
—
—
—
030
0.98
0.89
