Nipros DC-P175 - Manual

DC-P175
DC Cable for Panasonic P2
For using DC-P175.
Operating
Instructions
Before operating your DC-P175, please read this manual thoroughly and remain it for future reference.
■Features
・ Connecting to the DC power output 4-pin connector of the camera adaptor or the shoulder adaptor
ST-7, outputs the DC power to the Panasonic camera, AG-HPX255/250, 170 series, etc.
■Outsideview and Dimensions
■Specifications
Connector
Cable Length
1 Mini 4-pin connector, male
1 DC connector for Panasonic
0.5 m
Specifications
DC connector
for Panasonic AG-HPX255
AG-HPX250
170 series
Mini 4-pin connector
0.5 m
1
2
3
4
1
2 3
4
DC 8.4 V input
mini 4-pin (male)
DC8.4V(G)
NC
NC
DC8.4V(＋)
PROTECH accept no liability whatever for damages arising from improper use not conforming to the
instructions in the instruction manuals.
PROTECH accept no liability whatever for incidental damages arising out of the use or inability to use
the product, including, but not limited to, damage to the camera, etc., corruption or loss of data, lost
business revenue or suspension of business operations.
NOTE Features, design and specifications are subject to change without notice.
TM
