39
4
3
High
Low
1
Medium
1.5
8.4.2.4 Condenser high temperature T3 protection.
---131 ºF
runs at F1.If T3<129 ºF, the compressor will keep running at the current frequency.
---T3<126 ºF, the compressor will not limit the frequency and resume to the former frequency.
---T3>140 ºF for 5 seconds, the compressor will stop until T3<126 ºF.
8.4.2.5 Evaporator low temperature T2 protection.
---T2<32 ºF, the compressor will stop and restart when T2 >=41 ºF .
---32 ºF ≦ T2<39 ºF, the compressor frequency will be limited and decreased to the lower level
---39 ºF ≤ T2 ≤ 45 ºF, the compressor will keep the current frequency.
---T2>45 ºF, the compressor frequency will not be limited.
