6
The grommet
holes along
the edge of
the fixture
are designed
to allow the
fixture to be
screwed onto
set walls.
To remove the plate, pull up on the
locking pin and reverse the mounting
procedure.
To loosen or tighten the Lollipop
turn the Lock Lever. The Lever can be
adjusted so a 180
° turn provides the
necessary clamping strength.
Reorienting the Lever allows for further
tightening or loosening of the clamp.
To reorient the Lock Lever, pull Lever
away from mount. This disengages the
Lever from the screw mechanism and
allows it to be reoriented.
Note: You can also use a screwdriver
to adjust the travel. Pull back on Lever
and adjust the screw in the center of
the Lever.
