Kino Flo Mega 4Bank DMX (BAL-450M) - Manual (Page 14)

14
To Chase one lamp through multiple fixtures:
1) Set ballast to Individual Lamp mode.
2) Set each ballast with its own address: 001, 006, 011, 016 and
so on.
3) Program lamp sequence to chase from 001 through 004, 006-009,
011-014 and so on. (note: skipping the HO/STD function)
4) Set end of line switch to “I” on the last unit in the DMX chain.
To Chase same lamp position simultaneously through multiple
fixtures:
1) Set ballast to Individual Lamp mode.
2) Set each ballast address to 001 ( or a common address ).
3) Program lamps to chase from address 001-004.
4) Set end of line switch to “I” on the last unit in the DMX chain.
CFX-9604 8ft Mega 4Bank Fixture
CFX-7204 6ft Mega 4Bank Fixture
MTP-K81 Mega “Twist-On” Mount
w/Junior Pin
