8
1. Connect the harness to the Ballast.
Align the key ways on the harness
connector with the circular receptacle on
the ballast. Rotate the locking ring until
it clicks into the lock position.
2. Insert the 4 rubber feet of the ballast
into the 4 holes in the fixture.
3. Secure the Ballast
to the fixture with the
Velcro fastening strap.
The Foto-Flo fixture can be used
with the ballast directly attached
or remotely, using a 25ft extension
cable. Remote operation of the
ballast provides more diverse rigging
options.
To insert the cable, align the key
ways on the extension cable with
the circular receptacle on the ballast.
Rotate the locking ring until it clicks
into the lock position. Lamps can
operate as far as 75 feet from the
ballast. (3 x 25ft extensions)
