Kino Flo Foto-Flo 400 - Manual (Page 6)

6
Align the center pin of the
mounting plate to the center
hole on the mating plate.
Rotate plate clockwise until
the four shoulder rivets drop
into the receptacle. A locking
pin will snap into place when
the plate is properly seated.
Restricting the airflow around the lamps can cause the lamp
to operate hotter. This increased heat will raise the lamp’s color
temperature and green spike. Therefore, it is recommended to
clip gels to the Doors of the Fixture.
Do Not clip gels to louver.
Do Not block the fixture ends in a manner that restricts airflow.
