Kino Flo Foto-Flo 400 User Manual
Page 5
5
Locking Lamp Connector:
Depress both tabs on lamp connector and apply to lamp pins.
Match the Harness color-codes at each end of the lamp.
Push lamps into the fixture’s Lamp Holder Clips.
Lamp Harness Color Codes
The Harness wiring is color-coded. The same color-
code must match at each end of the lamp for proper
operation.
BLACK/RED
WHITE/YELLOW
WHITE/BLACK
BLACK/BLUE
Foto-Flo 400 Harness
