Ballast Operation continued….
(Note: The dimmer should be full up when striking the lamp. Once the lamp
has come up to full temperature, in 3-5 minutes, then dim to the desired
light level.)
In cold temperatures the Ballast may take longer to ignite the lamp. If it
does not ignite within 5 seconds, switch the ballast to OFF, and try again.
If lamp does not strike after 2 or 3 attempts, turn Ballast off, check that the
harness, lamp or any extension connections are secure and restrike.
A B C D
A) Lamp Output….. Lamp harness connects the ballast to the lamp.
B) Power Switch…. Lights up green when power is present.
C) TRIM …………… Adjusts the bottom end of the dimming curve.
D) DIMMER …..…… Adjusts the light level of the lamp.
