Kino Flo 12V Single Kit User Manual
Page 3
3
Fixture is comprised of 3
parts:
1. Fixture Shell
2. Lamp Harness
3. Black Louver
The Louver is held in place with
Velcro fasteners. Clips hold the
lamp to the fixture.
Locking Lamp Connector:
Depress both tabs on the lamp connector and apply to
lamp pins. Push lamp into the fixture’s Lamp Holder
Clips.
