7
Beam Angle Orientation
Correct Lamp Orientation
Vertical beam angle Horizontal beam angle
VERTICAL MODE:
Follow the principle of lamp base up and lamp tip down. This orientation keeps
the mercury away from the cathodes and provides best color temperature stability and
best color rendering.
DO NOT operate fixtures with lamp base in the down position. Color can diverge up to
400K and will get very green.
HORIZONTAL MODE:
Even in the horizontal position, a slight rotation favoring the lamp tips (lamp base higher
than the lamp tip) will allow for better color temperature stability.
Note:
When looking at the back of the fixture, the Kino Flo logo should read:
If the Logo is upside down, the fixture does not have the correct orientation.
