10
Fixture Operation
ParaBeam 410 DMX Control Panel
A) DMX-IN & DMX-OUT: DMX-In Receives DMX signals from dimmer board.
DMX-Out relays DMX signal through other fixtures or instruments.
(Note: Each ParaBeam 410 & 210 DMX fixture has an “AUTO TERMINATE” feature.
The last fixture that does not have an XLR cable attached to the DMX “Out” port will
automatically terminate.)
B) DMX Indicator Light: Lights if valid DMX signal is present.
C) DMX Channels/Manual DIM Lamps: Sets the ParaBeam 410 to use 1 or 2 DMX
Channels. (Note: ParaBeam 210 uses 1 DMX Channel.)
D) DMX Address: Sets DMX address of Fixture.
E) Dimmer Knob: Manual dimming control
Warning! To Ensure Proper Operation
ALWAYS TURN OFF THE FIXTURE BEFORE connecting or disconnecting lamps. After the
lamps are properly installed, the fixture can be turned on. Avoid operating in temperatures
above 125°F (51°C) or below 60°F (15°C).
In temperatures below 60°F or 15°C, the fixture may take longer to strike. If lamps do not
strike within 5 seconds, switch the fixture to OFF and try again. Check that the lamps are
properly seated and the dimmer is up full, then restrike. If temperatures are too low, try to
warm up the fixture to at least 60°F. Lamps will turn on at preset dimmer settings as long as
the temperature is above 60°F or 15°C.
A
B
C
D
E
