Inserting Gel Frame
Inserting Lamps
Open hinged reflector door.
Snap lamp pins into
lamp holder.
Silver louver or honeycomb
louver fits into front
channel.
Insert lamp end first.
Push tab down and forward
to lock into open position.
Insert gel frame into
channel closest to lamps.
Close reflector door.
To release lamps,
press Red button and
lift lamp out.
All 4 retaining tabs must
be extended to lock
accessories in place.
