6
Other Fixture Mounting Options
Extension Cable
The grommet holes along
the edge of the fixture are
designed to allow the fixture
to be screwed onto set walls.
To insert the cable, position the logo up to align the
key ways on the extension cable with the circular
receptacle on the ballast. Rotate the locking ring
until it clicks into the lock position.
Lamps can operate as far as 75 feet from the ballast
(3 x 25ft extensions).
A Splitter can be used at the Ballast or on the end
of an Extension Cable to split a Mega 4Bank run
into either four Mega Singles or two Mega Doubles.
This allows for greater rigging flexibility.
A Combiner can connect a number of smaller
ballasts to a larger fixture. For example, 4 Mega
Single Ballasts or two Mega Double Ballasts can be
combined to a Mega 4Bank Extension or Fixture.
