Extension Cable
6
Mounting to a Set Wall
Cardholders (MTP-IB) (x4)
The Flathead 80 has screw points within the fixture to allow it to be
fastened flat against a surface.
The Flathead 80 is equipped with unique cardholder corner brackets
that allow foam core panels to be clipped in place.
To insert the cable, position the logo up to
align the key ways on the extension cable
with the circular receptacle on the ballasts.
Rotate the locking ring until it clicks into the
lock position.
Fixture can operate as far as 75 feet from
the ballast (3 x 25ft extensions).
