Kino Flo Celeb 200 DMX LED - Manual (Page 17)

LVR-CE290-P Celeb 200 Louver/HP 90°
LVR-CE260-P Celeb 200 Louver/HP 60°
MTP-B41F Kino Offset w/ Baby Receiver (16mm)
Lollipops are interchangeable.
MTP-L Kino 41 Lollipop w/ 3/8” Pin (10mm)
MTP-LB Kino 41 Lollipop w/ Baby Receiver (16mm)
MTP-LBS Kino 41 Lollipop w/ Baby Receiver Short
(16mm)
17
Accessories
BRD-CE2 Celeb 200 Barndoors (Set of 4)
GFR-CE2 Celeb 200 Gel Frame
Troubleshooting continued
Can’t set the DMX address.
You must Press and Hold the DMX Address button for 3 seconds in order to
select an address. The display will flash while in edit mode. Select a valid
address from 1-512. (Note: 0 or 513 and higher are invalid addresses.)
Can’t operate the fixture manually with the DMX cable plugged in.
Two Options:
Set DMX address to “0” or disconnect cable and turn power off and on.
