13
Yoke Mount
MTP-I40 MTP-I80
The yoke has a ½” hole to accept industry standard mounting hardware.
The Celeb 200 Yoke Mount fixture can hang from a grid by a baby pipe hanger us-
ing a Baby Receiver Assembly for Yoke (MTP-I40), sold separately. It can also hang
by a junior pipe hanger using a Junior Pin Assembly for Yoke (MTP-I80), also sold
separately.
Note: The yoke also provides an attachment point for a safety chain.
Warning: Use only M5 X 10mm screws (supplied) to assemble yoke.
Note that threads on the fixture are self-locking and may seem tight.
Replacement screws: Part No. 2020127
Recommended torque setting:
USA: 18 lb-in
Metric: 2 Nm
Baby Offset Arm
The Kino Offset w/ Baby Receiver (MTP-B41F) allows fixtures to mount on the center
of a stand or it can also be under slung from a baby stand to use as an up light.
MTP-B41F Kino Offset w/
Baby Receiver (16mm)
