12
Center Mount
The Celeb 200 Center Mount fixture includes a Lollipop w/ Baby Receiver
(16mm) (MTP-LB) which allows the fixture to be mounted directly onto a
baby stand or hung from a grid with a baby pipe clamp.
Note: The handles on the back of the fixture provide an attachment point
for a safety chain.
MTP-LB Mounted on
a baby stand
Mounted to pipe grid
Lollipops are interchangeable.
MTP-L Kino 41 Lollipop w/ 3/8” Pin (10mm)
MTP-LB Kino 41 Lollipop w/ Baby Receiver (16mm)
MTP-LBS Kino 41 Lollipop w/ Baby Receiver Short
(16mm)
A 180° turn loosens the orientation of the mount.
A right turn tightens the mount.
The tension on the lock lever may be adjusted
by pulling the handle away from the mount.
This disengages the handle from the screw
mechanism and allows the lever to be reoriented.
You can also use a screwdriver to adjust the tension.
Pull back on handle and adjust screw.
