Inputs & Outputs
Phone Line Connection
7.
Phone Line
The RemoteMix 4 has an RJ-11 jack that can be connected to any standard,
single line analog telephone line. This jack should not be connected directly
to digital PBX or ISDN phone systems.
8.
Handset Interface
If you do not have access to an analog phone line or if the phone system
is a digital or analog PBX, ISDN, VOIP or a key telephone system, you can
use the built-in handset interface. Disconnect the telephone handset from
the coily cord and plug the cord into the RemoteMix 4
Interface> jack. Now select the handset type on the 3 position switch.
Trial and error works faster than a chart of handset types, but this basic
description may help.
9.
Cue Input / Wireless Phone Interface
RemoteMix 4 comes equipped with a
in to the 1/4”
designed 1/4” to 2.5 mm or 1/4” to 3.5mm cable provided with the unit.
This interface works with any wireless phone or notebook that accepts
standard third party headsets and earpieces. Some wireless phones have
the standard 2.5 mm TRS jack while others have a 3.5 mm TRRS jack and
others yet have proprietary jacks. Adapters to convert the proprietary jack
to a standard 3-conductor 2.5 mm or 4-conductor 3.5 mm jack are available
for most wireless telephones through their dealers, local electronic stores or
many internet stores.
10.
When using the wireless interface, it is important to keep your wireless
telephone 12” - 24” away from the RemoteMix 4 and any microphone or
headphone cables. This will help prevent unwanted RF noise from entering
the unit.
5
Getting to Know Your RemoteMix 4
Switch Position
Handset Microphone Type
A
Electret
B
Dynamic
C
Carbon
